Multiparameter weather station

1. Multiparameter weather station product introduction

The PQX8Multiparameter weather station is a highly integrated, low-power, quick-to-install, high-precision automatic weather observation equipment that is easy to use for field monitoring.

The equipment supports wireless transmission, requires no debugging, and can be quickly deployed.It is suitable for the acquisition of meteorological data such as short-term emergency meteorological observations and mobile meteorological monitoring.Widely used in meteorology, agriculture and forestry, environmental protection, oceans, airports, ports, scientific expeditions, campus education and other fields

The device uses an eight-element integrated sensor that can conduct real-time observations of meteorological elements such as wind speed, wind direction, temperature, humidity, air pressure, PM2.5, PM10, noise, etc.The sensor shell is made of imported Stainless steel material, which is more effective against salt spray and other environments.The protection level reaches IP65 or above.

2.Multiparameter weather station product features

1.The ultrasonic probe is hidden in the top cover to avoid interference from rain and snow accumulation and avoid obstruction by natural wind☆

2.The principle is to emit continuous variable frequency ultrasonic signals and detect wind speed and direction by measuring the relative phase☆

3.Eight-element integrated sensor of wind speed, wind direction, temperature, humidity, air pressure, pm2.5, pm10 and noise☆

4.Powered by lithium battery, with power display function

5.Shock-absorbing protective trolley case, easy to carry

5.Aluminum alloy bracket, retractable

6.7-inch Android touch screen

3.Technical parameters of Multiparameter weather station

1.Wind speed: 0~60m/s (±0.1m/s+0.01V);

2.Wind direction: 0~360° (±2°);

3.Air temperature: -40-80℃ (±0.3℃ (25℃));

4.Air humidity: 0-100%RH (±3%RH (20%~80%));

5.Atmospheric pressure: 300-1100hpa (±0.25%);

6.PM2.5: 0-1000ug/m3 (±10% (<500 micrograms));

7.PM10: 0-1000ug/m3 (±10% (<500 micrograms));

8.Noise: 30-120dB (±1.5dB)

9.Data storage: no less than 500,000 items;

10.Power consumption: 2W

11.Lithium battery: capacity 12000maH, battery life ≥32h

12.Total weight of equipment: ≤5kg;

13.Installation time: 1 person, no more than 2 minutes to complete the installation;

14.The production enterprise has ISO quality management system, environmental management system and occupational health management system certification.

15.The production enterprise has a computer software registration certificate

16.The production enterprise is a 3A credit enterprise

4.Introduction to Multiparameter weather station cloud platform

1.CS architecture software platform supports direct observation on mobile phones and PC browsers without the need to install additional software.

2.Support multiple accounts and multiple devices to log in

3.Support real-time data display and historical data display dashboard

4.Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.

5.Support SMS alarm and threshold setting

6.Support map display and view device information.

7.Support data curve analysis

8.Support data export table format

9.Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.

10.Support data post-processing function

11.Support external running of javascript scripts
