location：Home>Product>Photovoltaic Inspection>Solar Simulators>Solar simulation systems

Solar simulation systems

Model：FT-MT1

Brand：fengtu

1.Solar simulation systems product overviewSolar simulation systems provide an environment close to natural sunlight, achieving 24-hour uninterrupted lighting without being affected by environmental, climate and time factors. They are widely used in solar cell characteristic testing, dye-sensitized

Get a Free Quote

Product details
Related products
Related articles

1.Solar simulation systems product overview

Solar simulation systems provide an environment close to natural sunlight, achieving 24-hour uninterrupted lighting without being affected by environmental, climate and time factors. They are widely used in solar cell characteristic testing, dye-sensitized cells (DSSC), perovskite cells (PSC), photoelectric material characteristic testing, biochemical related testing, photocatalytic degradation acceleration research, skin cosmetics testing and environmental research, etc.

2. Solar simulation systems product features

1. Advanced intelligent regulation of irradiation intensity, which can adjust the irradiation intensity according to the experimental requirements and experimental stages.

2. The lighting direction is vertically upward and downward, horizontally left and right. It can illuminate in four directions.

3. The irradiation area can be customized according to the needs, 1-100 square meters

4. Three intelligent controls: manual control, client control, and cloud control.

5. Fan power-off delay function: after shutdown, the equipment cooling system will delay power-off processing, without manual supervision, saving working time and increasing equipment service life.

6. Super long service life: The life of the bulb is more than 2000 hours.

3. Solar simulation systems technical indicators

name	Technical specifications
Irradiation area	1～100 square meters, customized according to experimental requirements
Light source type	Long arc pulsed xenon lamp
Light unevenness	±10%
Light instability	±10%
Spectral distribution	Class B
Control method	Manual, client, and cloud control
Cooling method	Delayed air cooling
Work Environment	Ambient temperature: -20～40℃, relative humidity: ≦70%
Power supply mode	AC380V, three-phase five-wire input
Lamp life	2000 hours
Light direction	Vertically up and down, horizontally left and right
Radiation Intensity	400～1800 W/m2
Light source output	Parallel light irradiation
