Non Contact Road Condition Sensor

Non Contact Road Condition Sensor Product Introduction

The LM2 is a Non Contact Road Condition Sensor that uses remote sensing technology to avoid damage to the road and thus avoid traffic interference caused by the installation of road weather stations. Multi-spectral measurement technology enables accurate detection of the thickness of icy, snow and water on the surface of the road. In road conditions where the embedded pavement sensor is inconvenient or inaccessible, the LM2 detector is the ideal choice. Remote sensing installation means no need to close the road or cut the road surface, and the installation work is both safe and convenient. Low maintenance is an ideal choice for the composition of road meteorological systems. It can be installed on existing weather stations or on other buildings with unobstructed views of the road surface.

The LM2 detector is installed in an all-weather, durable housing to ensure that it can withstand severe weather, which allows it to provide accurate data in any weather conditions. By providing road surface condition information, the LM2 detector provides accurate monitoring data to the road management department and takes response measures before road safety risks occur. Rugged design, all-weather measurement

Non Contact Road Condition Sensor Features

Test the road area, water, snow, and icing thickness

Long distance remote sensing to detect road conditions

Non-buried installation is fast and easy

Low maintenance cost

Integrate into existing highway automatic meteorological monitoring network applications

Long distance installation

Bridge surface

Areas with frequent accidents

Areas with high traffic flow

Characteristics of areas with frequent rain and snow

Long distance measurement of road area water, ice and snow

Measure the road state

Measure the degree of water accumulation, ice surface, slipperyness

Non-buried design

Resistant to rust

Infrared detection up to 15 meters

No need for closed lanes, easy installation and maintenance

Non Contact Road Condition Sensor Key Metrics

Model LM2

Monitoring distance 2-15 meters

Detection diameter 23cm angle 30-90 degrees

Power input 220VAC, 24VDC

Maximum power consumption 5W (including lens heating)

Operating temperature -38ºC to +70ºC

Operating humidity 0 to 100%

Road state parameter output

Road area water thickness: 0.00-10mm Resolution: 0.01mm Accuracy: 0.1mm

Pavement ice thickness: 0.00-10mm

Road area snow thickness: 0.00-10mm

Pavement slippery degree: 0.00-1 resolution: 0.01 (*)

Pavement temperature: -38ºC to +60ºC (*)

Pavement humidity: 0-100% (*)

Ambient temperature and humidity: -40ºC to +70ºC (*)

Atmospheric pressure: 150-1100hPa

Pavement status report dry, damp, wet, snow, ice, ice water mix (*frost)

Lens pollution detection optical lens pollution level measurement and internal automatic pollution compensation

Pavement materials concrete and asphalt pavement

Communication RS485, RS232

Average failure-free 10 years

No security issues

Infrared remote sensing measurement technology

Note: * marked parameters are optional, not standard.
